preface

Basalt is globally recognized as the best material for construction of highway, railway, and airport runway. While granite is widely used in architectural ornament and greatly enhances the value of real estate. Both granite and basalt are in great demand and have a promising investment prospect. However, hard rocks like basalt and granite are difficult to crush, which obstruct their extensive use. To solve this problem, Kefid offers the most professional hard stone aggregate crushing solution.

  • Granite is known as "the king of rock" because it has uniform structure, solid quality, beautiful color, good durability. It is a high-quality building stone, can be used from roof to floor in the building. Moreover, after crushing, it can be made into cement or rock for dam filling. Besides, granite is not easily weathered, nice-looking in color. Its color and lustre can keep more than one hundred years, so it is not only widely used as advanced architectural decoration, ground floor in hall but also the first choice for outdoor sculpture. Compared with the ceramics or other synthetic material, granite is much rare. So granite floor can greatly increase the value of real estate. And natural granite countertops have distinct temperature tolerance, is the preferred choice for all kinds of construction plate production.
  • Basalt is internationally recognized as the best material for construction of highway, railway, and airport runway because of its strong pressure resistance, low crushing value, strong corrosion resistance and good asphalt adhesion. Moreover, basalt is good aggregate for high-rise building lightweight concrete. It has many and hard porosity. Blending it in concrete can save the concrete weight without weakening any strength. Meanwhile, it also has the characteristics of sound and heat insulation. All the above advantages make basalt super favored by building material market. The high demand for raw basalt proves that it is a bright investment in basalt crushing project.

CLASSIC DESIGN OF CRUSHING LINE

jaw crusher

Secondary high efficiency
hydraulic cone crusher

The cone crusher crush the stone from the stockpile and then the crushed stone is trans- ported to the vibrating screen. After screening, the bigger stone is brought back to the stockpile and smaller stone is transported to tertiary crusher.

Primary heavy duty
jaw crusher

The jaw crusher is fed by the vibrating feeder continuously, and does the primary crushing process for the comp- lete line. The crushed stone will be transported to the vibrating screen to separate or to the stockpile before secondary crusher.

cone crusher

Tertiary good performance hydraulic
impact crusher/VSI sand making machine

The impact crusher/VSI sand making machine will take the stones coming from the cone crusher, and do the tertiary crush and reshape work. The products come out from the impact crusher/VSI sand making machine will go to the screen to separate.

impact crusher
150-200m³/h Basalt Stationary Crushing Line

150-200m³/h Basalt
Stationary Crushing Line


Raw material : basalt
Max input size : 660mm
Final product size : 0-5, 5-12,
12-21mm
Capacity : 150-200m³/h

Design Description :

This is a stationary three-stages crushing plant, including ZSW1300x4900 vibrating feeder+ HJ110 high efficiency jaw crusher+ HPT300/C hydraulic cone crusher+ PFS1415 hydraulic impact crusher+ 3YKN2460 heavy type vibrating screen. The design capacity is 150-200m3/h, with the function of crushing, screening and reshap- ing.

The advantage of this line is: tertiary crushing of PFS1415 hydraulic impact crusher, customer can get more cubic shape material, which can sell pretty good price in market.
150TPH Granite Stationary Crushing Line

150TPH Granite
Stationary Crushing Line


Raw material : granite
Max input size : 630mm
Final product size : 0-5, 5-20,
20-40, 40-70mm
Capacity : 150t/h

Design Description :

This is a stationary three-stages crushing plant, including ZSW1100x4200 vibrating feeder+ PE750x1060 jaw crusher+ CSB160C Symons cone crusher+ VSI5X8522 sand making machine+ 2YZS1860/4YZS1860 vibrating screens. The design capacity is 150TPH, with the function of crushing, screening and reshaping.

The advantage of this line is: after secondary crushing, the sizes 0-40mm will be processed by sand making machine, which increases the percentage of 0-5-20mm in final products, and insure the high quality cubic shape material.

JC Series Jaw Crusher

OUTPUT SIZE: 10mm to 275mm
PRODUCTION CAPACITY: Up to 650TPH

HPT Cone Crusher

OUTPUT SIZE: Min. discharge to 13mm
PRODUCTION CAPACITY: Up to 700TPH

Impact Crusher

OUTPUT SIZE: Various sizes
PRODUCTION CAPACITY: Up to 350TPH

Deep Rotor VSI Crusher

OUTPUT SIZE: Various sizes
PRODUCTION CAPACITY: Up to 640TPH
